Abrasive Blast Nozzles

High-performance blast nozzles THAT maximize your productivity

Standard Long Venturi Nozzles

Standard Long Venturi (or SLV) blast nozzles accelerate the abrasive velocity, creating a wide blast pattern which is ideal for blasting larger surfaces.

SLV blast nozzles are highly productive and suitable for most jobs, so they are included with all of our blast pots and mobile trailers.

  • Tungsten carbide lining provides long life and durability, even under rough handling.
  • Polyurethane jacket is lightweight to reduce operator fatigue.
standard-long-venturi-slv-cross-section-diagram-trimmed-1
long-venturi-slv-blast-pattern-illustration-1

Wide Blast Pattern

Versatile and all-purpose.

tungsten-carbide-molecule-1

Tungsten Carbide Lined

Unmatched durability in harsh conditions.

SLV4-w-shadow
SLV #4


$195

SLV5-w-shadow
SLV #5


$210

SLV6-w-shadow
SLV #6


$250

SLV7-w-shadow
SLV #7


$275

Not sure which size you need? Keep scrolling to see our size chart.


Short Venturi Nozzles

Short Venturi nozzles deliver a tighter stream of blasting media in a concentrated pattern with little overblast. They are ideal for spot blasting, precision work, and railings.

These nozzles may be used when blasting 12″ or less from the surface.

  • Tungsten carbide lining
  • Polyurethane jacket and threads are lightweight to reduce operator fatigue.
short-venturi-cross-section-diagram-trimmed-1
short-venturi-blast-pattern-illustration-1

Precision Blast Pattern

For detail work.

tungsten-carbide-molecule-1

Tungsten Carbide Lined

Unmatched durability in harsh conditions.

ST-Nozzle-w-shadow
ST #4


$162

ST-Nozzle-w-shadow
ST #5


$162

ST-Nozzle-w-shadow
ST #6


$162


XL Performance Nozzles

XL Performance nozzles increase abrasive particle velocity, resulting in improved production rates and efficiencies. This also allows you to use a larger standoff distance, covering more ground in less time.

XL Performance nozzles will utilize the same air requirements (CFM) as the same sized SLV nozzle, resulting in lower operating costs.

  • Tungsten carbide lining
  • Aluminum jacket and threads are lightweight and durable.
xl-performance-cross-section-diagram-trimmed-1
xl-performance-blast-pattern-illustration-1

Largest Blast Pattern

Allows a larger standoff distance.

tungsten-carbide-molecule-1

Tungsten Carbide Lined

Unmatched durability in harsh conditions.

XL5-w-shadow
XL #5


$555

XL6-w-shadow
XL #6


$555


Fan Nozzles

The fan nozzle's unique shape produces a rectangular blast pattern that is excellent for quickly covering a large surface area.

It is best for medium cleaning and stripping applications where an even dispersion of the abrasive throughout the wide uniform blast pattern is required.

  • Tungsten carbide lining
  • Polyurethane jacket and threads
fan-nozzle-cross-section-diagram-trimmed-1
fan-nozzle-blast-pattern-illustration-1

Rectangular Blast Pattern

Rectangular Blast Pattern

tungsten-carbide-molecule-1

Tungsten Carbide Lined

Unmatched durability in harsh conditions.

fan-Nozzle-w-shadow-1
Fan Nozzle


$363.10

Determining your nozzle size

To find your most productive nozzle, find out the following:

  • What volume of available air does your compressor can supply per minute (CFM)
  • What is the desired nozzle pressure (PSI) you want to maintain for productive blasting

Next consult the chart to find the nozzle orifice size that meets those parameters.

psi-chart-sized-for-web
long-venturi-slv-blast-pattern-illustration-1
SLV6-w-shadow

SLV Nozzle

Versatile & All-Purpose

Available in sizes #4 – #8

Tungsten Carbide Lining

Polyurethane Jacket

Brass Threads

Produces a wide blast pattern with a "hotspot" in the center

short-venturi-blast-pattern-illustration-1
ST-Nozzle-w-shadow

Short Venturi Nozzle

Precision Work

Available in sizes #4 – #6

Tungsten Carbide Lining

Polyurethane Jacket

Polyurethane Threads

Produces a small blast pattern for detail work

xl-performance-blast-pattern-illustration-1
XL5-w-shadow

XL Performance Nozzle

Maximum Blast Velocity

Available in sizes #5 – #6

Tungsten Carbide Lining

Aluminum Jacket

Aluminum Threads

Produces a larger blast pattern than others, with the same air volume

fan-nozzle-blast-pattern-illustration-1
Email - Fan Nozzle with Shadow

Fan Nozzle

Cover Large Areas

3/8"

Tungsten Carbide Lining

Polyurethane Jacket

Polyurethane Threads

Produces a rectangular pattern for large areas

Using the right nozzle makes all the difference in your productivity.
